Cryptocurrency ATM machine producer Bitcoin ATM Kiosk hardware and software provider
hunghui is the Bitcoin ATM produced The Bitcoin machine represents a solid ATM with all AML/KYC features required. By request an optional finger print scanner could be added. SMS verification function, identification card reader, and a high-definition camera could be used in order to comply with regulations in place.
This is a two-way Bitcoin ATM, so both fiat money to Bitcoin, and Bitcoin to cash transactions could be done. Interesting is the fact that this ATM supports three cryptocurrencies: Bitcoin, Litecoin and Dogecoin, which is opposite to only Bitcoin normally with other ATMs.
Product Parameters:
| Components | Details |
| PC system | Industrial Board | H81 industrial mainboard(Advantech /Gigabyte/Ausa/Others) |
| CPU | Dual core G3260, 3.3ghz; Intel Dual Core I3/I5/I7 |
| RAM | 4 GB / 8GB |
| HDD/SSD | 500G/120G |
| Interface | 10 RS-232 Ports;1 LTP;8 USB Ports,1 100/1000M Net Port ;Integrated Net Card, Sound Card |
| PC Power Supply | HUNTKEY/Great Wall |
| LCD monitor | Screen Size | 17 inch/19inch ( optional from 8inch to 65inch) |
| Brightness | 250cd/m2( optional from 250cd/m2 to 2000cd/m2) |
| angle | horizontal 100°above;Vertical 80°above |
| Contrast | 1000:01:00 |
| Backlight tube life | more than 40,000hours |
| Max. resolution | 1280×1024 |
| Touch screen | Screen Size | 17/19 inch Diagonal ( optional from 8inch to 65inch) |
| Resolution | 4096x4096 |
| High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times |
| Bank/Credit Card Reader | Interface | RS232 |
| Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card |
| Power Voltage | DC 24V±5% |
| Card Entry method | Magnetic signal, Optoelectronic signal and rear card signal |
| EPP/Encrypted Pinpad | Interface | RS232/USB |
| Keylift~span | 2,000,000 cycles |
| Key force | 2~3N |
| Key trip | >2.5mm |
| Compliance: | PCI 4.x approval |
| Protection level | ip65 |
| Cash recycler | Validation Rate | 99% or higher |
| Notes recyler capacity: | 70 notes |
| Banknote Insertion | Four-way |
| Escrow | One banknote |
| Capacity | 1200 notes Max |
| QR Scanner | Support 2D Code(GM , MICRO QR,MICRO PDF417,QR Code , Data Matrix, Chinese-Sensible Code,etc.) |
| One-Dimensional Code(Code 128, EAN-13, EAN-8, Code39s Code93s UPC-A, etc.) |
| Can support to scanner Mobile phone or paper's QR/barcode |
| Resolution Ratio:640x480 pixels |
| Camera | With 1080p high-def, H.264 video compression, and a wide 90-degree field of view.2 Million Pixels |
| receipt thermal printer | Autocutter | included |
| Technology | Thermal printing |
| Paper width | 80mm |
| Printing speed | 150mm/s |
| Data buffer | 4KB |
| Interface | RS232 ,USB |
| Digital Power Supply | AC input voltage range | 100~240VAC |
| Frequency | 50Hz to 60Hz |
| AC input voltage range | 100~240VAC |
| Frequency | 50Hz to 60Hz |
| Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. |
| Operation System | Windows 7 or Windows XP operation system without license |
| KIOSK Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. |
| Packing | Security Packing method with bubble foam and wooden case |
Applications:
Banks
Hotel
Hospital
Theatre
Railway Station
Metro Station
Parking Lot
Shopping Mall
FAQ:
Q1: Are you manufacturer?
A1: Yes, we're and OEM & ODM is accepted
Q2: What's your MOQ?
A2: One sample is available.
Q3: What's the lead time?
A3: 7~35 days
Q4: What's your guarantee for Cryptocurrency Kiosk?
A4: 1 year guarantee from the shipping date.
Q5: What is your payment methods ?
A5: T/T, L/C, Western Union, Credit Card, MoneyGram,etc.
Q6: What is transportation way?
A6: By sea,by air, by courier
Q7: What is your trading terms?
A7: EXW, FOB,CIF,DDU,is our common trading terms
